Well Pump Repair
No water at the house, pressure that keeps dropping, or a pump that never shuts off. We check the system in order and repair or replace the part that failed.
Learn More
A well pump moves water from the well into your house. Core Well Drilling handles well pump installation on new and existing wells across the Upstate. The work covers the pump, the drop pipe, the pitless adapter, the pressure tank and switch, and the wiring. When we are drilling a new well, the pump system goes in as part of the same job.
The pump has to match the well. Depth to water, what the well makes and what your household uses all set the pump size. We look at those numbers before we put a price on the job. If your well already has a pump that quit, start with well pump repair.
Tell us about the job. We will get right back to you.
A house well system has parts down the hole and parts up top. Down the well sits the submersible pump, hung on drop pipe with the pump wire strapped alongside it. The pump pushes water up the pipe instead of pulling it from the surface.
At the wellhead, a pitless adapter carries the water sideways out of the casing below the frost line. It seals the top of the well and keeps that connection from freezing, so no well pit is needed. South Carolina's well standards call for casing that stands at least a foot above the ground, capped at the top.
Inside the house or the well house, the pressure tank and switch hold steady water pressure. The switch has a cut-in pressure that starts the pump and a cut-out pressure that stops it. We check the tank's air precharge before the tank is plumbed in, since that setting belongs just under the cut-in. Tank sizing and replacement are covered on our well pressure tanks page.
Jet pumps sit above the well and pull water up with suction. A shallow well jet pump works where the water stands less than 25 feet down. A submersible pump sits under the water in the well and pushes the water up the pipe.
Drilled wells in the Upstate go through soil and weathered rock into hard Piedmont bedrock. Two Spartanburg County wells logged by the state are 6 inches across and 225 and 442 feet deep. A well that size takes a submersible pump. It moves more water than a jet pump on the same size motor.
Jet pumps still have a place on a shallow well or a narrow well. The tradeoff with a submersible is service, because it has to come out of the well to be worked on. So the drop pipe, the wire and the fittings down the hole matter as much as the pump.
Pump size starts with the numbers from the well. How deep the water sits and what the well makes in gallons per minute both matter. Then we look at the house. A household with seven people needs more gallons per minute than a household with two.
In the Upstate, yield comes from the fractures the well hits, so it changes from lot to lot. A study of more than a thousand Upstate wells put the middle yield near 8 gallons per minute. Those wells sit in Spartanburg, Greenville and northern Pickens counties. We size the pump to what your well makes.
A well feeding a sprinkler system, livestock or a pond pulls more water than a house well. Those get a pump built for the higher draw, and we cover them on our irrigation wells page. On a replacement, we size the new pump to the well as it is today.
Free estimates and site visits across the Upstate, about 60 miles around Spartanburg.
(864) 768-5688From the first call to water at the house, here is how it goes.
Call (864) 768-5688 and tell us where the land is and what the water is for. If we are on a job, leave a message and we will get back to you.
We look at the property before the job is scheduled. Setbacks matter here, since the state well standards keep a well 75 feet from a septic tank or drainfield.
The estimate quotes a minimum depth for your well. Bedrock depth is not something anyone can see from the surface, so the estimate explains how casing cost can change.
The rig drills through soil and weathered rock into the bedrock below. Casing is set into that rock and grouted, then the well is developed until the water runs clear.
We size the pump to the depth and yield of your well. Then we set the drop pipe, the pitless adapter and the pressure tank. The water line runs to the house and the water comes on.
Common questions about well pump installation across the Upstate, about 60 miles around Spartanburg. If yours is not here, call and ask.
No water at the house, pressure that keeps dropping, or a pump that never shuts off. We check the system in order and repair or replace the part that failed.
Learn More
A well pressure tank holds water under pressure so the pump does not run every time a faucet opens. We install and replace pressure tanks across the Upstate, sized to the pump on your well.
Learn More
Irrigation and farm wells for sprinkler systems, livestock, ponds and pools around the Upstate. We size the pump to the well and run the line out to the field.
Learn MoreCore Well Drilling is licensed and bonded in South Carolina. Every well is built to the state well standards. The well record is filed with the state when the job is done.
Our drillers bring more than 40 years of drilling experience. Two wells a mile apart can hit rock at very different depths. That experience shows in where we put the well.
We look at the property before the job is scheduled, so the well goes where it works best. The written estimate quotes a minimum depth, and estimates are free.
You call one number for the well, the pump, the pressure tank and the water line. The same number gets you well pump repair years down the road.
